Maximizing efficiency and precision in your workflow.

Supfina Spiro provides you with an optimal fine grinding solution for the production of highly precise plane-parallel functional surfaces, whatever your needs.

Economical Fine Grinding

with proven Supfina precision

No matter your workpiece properties, the Supfina Spiro offers an ideal fine grinding solution for your most stringent tolerance and material requirements.

We work closely with you to determine your wants and needs and fine a solution based on your budget. Precision without compromise, it’s our lifelong promise.

Spiro line

Key features

  • High drive performance
  • Maximum flexibility for many applications
  • Individually customizable for optimal machining results
  • Reduced tool wear thanks to the low-vibration machine stand and guard
  • High-precision, noncontact measurement control
  • Visual process control for consistently high precision
  • User-friendly and intuitive operation
  • Great accessibility

Spiro F5

Compact design, great performance

The Supfina Spiro F5 was specially developed for fine grinding smaller workpieces that require highly precise plane parallelism. It’s the perfect fit for your needs.

  • 100-program storage
  • Integrated sharpening programs
  • Up to seven process cycles
  • Optional loading table
Workpiece specifications
Wheel diameter445 / 475 mm
Ring width120 / 150 mm
Maximum pressure300 daN
Workpiece diameter4 – 150 mm
Workpiece thickness0,3 – 50 mm

Spiro F7

Fine grinding in large-scale production

The flexible Spiro F7 fine-grinding machine is ideal for creating precise flat surfaces on workpieces made from a wide variety of materials.

  • Memory for 192 programs
  • Rigid machine concept
  • User-friendly, thanks to visual-process control
Workpiece specifications
Wheel diameter720 mm
Ring width200 mm
Maximum pressure1800 daN
Workpiece diameter5 – 220 mm
Workpiece thickness0,6 – 80 mm

Spiro F12

For large workpieces

Our largest Spiro machine is designed to process workpieces with diameters of 6 mm to 420 mm and with special height, parallelism, and flatness requirements, all with high precision and cost-effectiveness.

  • Energy-efficient, low-maintenance drive concept
  • Very good accessibility
  • User-friendly, thanks to visual-process control
  • Flexible connection to different loading systems

Advantages of using a torque motor

  • Energy efficient with very high initial torque
  • No vibration due to geared components
  • Direction change without backlash or loss of motion
  • New machining sequences possible
  • Maintenance-free operation
  • No gear oil required
  • Smaller footprint
  • Maximum rigidity
Workpiece specifications
Wheel diameter1160 mm
Ring width341 mm
Maximum pressure3000 daN
Workpiece diameter6 – 420 mm
Workpiece thickness1 – 100 mm

A range of options

Manual to fully automatic

We know your workflow is unique to your processes. Our wide range of loading and unloading options can meet any stringent needs.

From short cycle times to reduce downtime, short set-up times and flexible adaptation to different feeding systems and visual process control, Supfina finds your perfect solution for all these tasks.

Learn more ...

Highlights

Modern Controls

The user-friendly and intuitive operation, combined with visual process control, ensures consistently high precision.


Automation

The utilization of a carrier exchange tool is just one of the many ways to improve efficiency automation in the Spiro.

Learn more ...

Loading Tables

The Spiro F5 fine grinding machine can include the use of an optional loading table for manual loading and unloading purposes.


Case Study

Supfina recently partnered with The Timken Company with their complex automation needs, customizing a Spiro F5 with material handling robotics.


Learn more ...

Case Study

the Swiss company MPS Micro Systems AG was looking for an opportunity to rapidly .expand its capacity in the manufacture of micro components without compromising on processing quality

Learn more ...

Case Study

With the newly delivered Supfina Spiro F7 fine grinding machine, the precision parts specialist URBEN + KYBURZ AG, Switzerland, is expanding its product range and competitiveness.


Learn more ...

Cutting Edge Technology

No matter the material, the job can be done to the most stringent requirements.


Learn more ...

Brochure

 See which Spiro fine grinding machine works for you, complete with technical information and specs.

Download ...
